:ROUTe:CHANnel:DEScription
Description
Set channel description. The channel description will be stored in flash memory after it is
set.
If dev num <= 2  max chnl =(dev -1)*64 + chan - 1
If 2 < dev num <= 4  max chnl =(dev -1)*32 + chan -1
If 4 < dev num <= 8  max chnl = (dev -1) *16 + chan -1
Max channel must be smaller than 128
Input Format
:ROUTe:CHANnel:DEScription <dev>,<chan>,<des>
Parameter
Type
Value
<dev>
Integer
device (1 – 8)
<chan>
Integer
output channel(1 –128)
<des>
String
description (length < 64)
Output Format
None
Default
0
Example
The following example sets channel description “TEST channel” for channel 1 of device 1.
Terminal Input:
:ROUT:CHAN:DES 1,1,TEST channel
