Multiple ATM Example
IF Hex Digit Example IF Type
LAN 0 N/A N/A
WAN Base A +2 ATM 0 ATM
WAN Base A: VLAN A +3 ATM 0.1: PVC 0/35 VLAN Null Tag
WAN Base B +4 ATM 1 ATM
WAN Base B: VLAN A +5 ATM 1.1: PVC 0/36 VLAN Null Tag
PTM / ATM Example
IF Hex Digit Example IF Type
LAN 0 N/A N/A
WAN Base A +2 PTM 0 PTM
WAN Base A: VLAN A +3 PTM 0.1: VLAN Null Tag
WAN Base A: VLAN B +4 PTM 0.2: VLAN 101
WAN Base B +5 ATM 0 ATM
WAN Base B: VLAN A +6 ATM 0.1: PVC 0/35 VLAN Null Tag
WAN Base D +7 ATM 1 ATM
WAN Base D: VLAN A +8 ATM 1.1: PVC 0/36 VLAN Null Tag
ETHERNET / ATM Example
IF Hex Digit Example IF Type
LAN 0 N/A N/A
WAN Base A +2 Ethernet 4 Untagged ETHERNET
WAN Base B +3 ATM 0 ATM
WAN Base B: VLAN A +4 ATM 0.1: PVC 0/35 VLAN Null Tag
