SHB 28Z3 EN – Edition 2.0 * 28z3s510.fm 5-3
Hydraulic system
8
10
9
Variable displacement pump unit Gear pump unit
7
Pos.
Designation
7
Suction line Port
8
Port PB1 (gear motor supply)
9
Port PA (2nd speed range)
10
Port PB2 (pilot valve supply)
