SHB 28Z3 EN – Edition 2.0 * 28z3s210.fm 2-17
Specifications
2.19 Lift capacity table 28Z3 VDS (short stick)
All table indications in kg (lbs.) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The machine's lift capacity is restricted by the settings of the pressure limiting valves and
the hydraulic system's stabilising features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
3.5 m (11'6”) 3.0 m (9'10”) 2.5 m (8'2”) 2.0 m (6'7”)
B\A
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
Lowered
blade
Raised
blade
3.0 m
(9'10”)
516*
(1138*)
403
(889)
444
(979)
495*
(1091*)
464
(1023)
495*
(1091*)
2.0 m
(6'7”)
501*
(1105*)
303
(668)
333
(655)
508*
(1120*)
348
(767)
382
(842)
549*
(1235*)
448
(988)
494
(1089)
628*
(1385*)
599*
(1321*)
628*
(1385*)
1.0 m
(3'3”)
507*
(1118*)
275
(606)
303
(668)
573*
(1263*)
329
(725)
363
(800)
690*
(1521*)
413
(911)
458
(1010)
912*
(2011*)
536
(1182)
601
(1325)
0.0 m
(0'0”)
517*
(1140*)
289
(637)
319
(703)
589*
(1299*)
317
(699)
351
(774)
743*
(1638*)
392
(864)
437
(963)
979*
(2158*)
509
(1122)
572
(1261)
1366*
(3012*)
715
(1576)
821
(1810)
-1.0 m
(-3'3”)
506*
(1116*)
375
(827)
416
(917)
579*
(1276*)
399
(880)
444
(979)
783*
(1726*)
516
(1138)
580
(1297)
1044*
(2302*)
731
(1612)
838
(1848)
Fig. 7: Lift capacity table (model 28Z3)
max Admissible load on extended stick
A Reach from live ring centre
B Load hook height
* Lift capacity limited by hydraulic system
With the stabiliser blade in driving direction
Without the stabiliser blade, 90° to driving direction
