SHB 28Z3 EN – Edition 2.0 * 28z3s312.fm 3-27
Maintenance
3.11 Change cab air filter
Caution!
The filter elements will be damaged if they are washed or brushed out!
☞ Never reuse damaged filter elements.
☞ Ensure cleanliness when replacing the filter elements!
Caution!
Clean the filter elements only with compressed air, bearing in mind the
following:
☞ Wear goggles and protective clothing
☞ Carefully clean the filter with compressed air
☞ Do not aim the compressed air at the skin or at other people
☞ Do not use compressed air for cleaning your clothing
The machine is equipped with a cab filter located under the seat.
Clean the cab filter every 500 service hours, and replace it every 1000 service hours.
☞ Stop the engine
☞ Remove the ignition key and carry it with you
☞ Fold the control lever base up
☞ Remove screws A and the cover
☞ Remove the filter and clean or replace it
☞ Install the filter
☞ Mount screws A and the cover
Fig. 27: Cab air filter cover
A
