SHB 28Z3 EN – Edition 2.0 * 28z3s210.fm 2-19

Specifications

2.21 Kinematics

E Pin diameter 40 mm (1.57”)

F Stick width 140 mm (5.51”)

L Pin distance from bucket mount 180 mm (7.09”)

Bucket

Stick
