2-12 SHB 28Z3 EN – Edition 2.0 * 28z3s210.fm
Specifications
Main data Model 28Z3 VDS
Service weight with cab/canopy 3070/2977 kg (6768/6563 lbs.)
Transport weight with cab/canopy 2910/2817 kg (6415/6210 lbs.)
Height 2525 mm (8'3”)
Width 1570 mm (5'2”)
Transport length (short/long stick) 4200 mm (13'9”)/4240 mm (13'11”)
Max. digging depth (short/long stick) 2420 mm (7'11”)/2620 mm (8'7”)
Standard stick length (short stick) 1050 mm (3'5”)
Long stick length (long stick) 1250 mm (4'1”)
Max. vertical digging depth (short/long stick) 1845 mm (6'1”)/2035 mm (6'8”)
Max. digging height (short stick) 4300 mm (14'1”)
Max. digging height (long stick) 4430 mm (14'6”)
Max. dump height (short stick) 2960 mm (9'9”)
Max. dump height (long stick) 3090 mm (10'2”)
Max. digging radius (short stick) 4614 mm (15'2”)
Max. digging radius (long stick) 4815 mm (15'10”)
Max. reach at ground level (short stick) 4443 mm (14'7”)
Max. reach at ground level (long stick) 4644 mm (15'3”)
Max. breakout force at bucket tooth 22.5 kN (5058 lbs/ft)
Max. tearout force (short stick) 13.6 kN (3057 lbs/ft)
Max. tearout force (long stick) 21.9 kN (4923 lbs/ft)
Min. tail end slewing radius 760 mm (2'6”)
Max. tail end lateral projection (90° rotation of upper carriage) 0 mm (0'0”)
Max. boom displacement to bucket centre (right-hand side) 533 mm (1'9”)
Max. boom displacement to bucket centre (left-hand side) 764 mm (2'6”)
Max. tilt angle for VDS 15°
