Introduction
Meaning
Potential high pressure grease discharge from the track tension adjustment fitting.
Always read the Operator’s Manual before working with the track tensioner.
Position
On either side of the travel gear.
Meaning
Entanglement hazard.
Stop the engine before opening or removing the safety devices (for example engine cover,
fan guard)
Position
On the front side of the engine cover
Meaning
Cutting hazard. Cooling fan can cut when rotating.
Stop the engine before opening the engine cover!
Stay clear of the engine compartment if the fan is still running!
Meaning
Entanglement hazard. You can be pinched or entangled in the engine V-belt when the
engine is running.
Stay clear of the engine compartment with the engine running!
Perform work in the engine compartment at engine standstill only.
Burn hazard. Hot surface. Do not touch. Contents are under pressure.
Allow the reservoir to cool down!
Carefully and slowly open the cover only after the reservoir has cooled down, to
release the pressure.
Wear suitable protective clothing to open the cover.
Position
In the engine compartment
Fig. 22: Tightening the tracks
Fig. 23: Stopping the engine
Fig. 24: Fan in engine compartment
Fig. 25: Hydraulic oil reservoir under pressure
