BA 50Z3/6003 en – Edition 4.3 * 5003b330.fm 3-55
Operation
Closing the whole front window
☞ Press levers A on the left and right, and pull the entire front window downward with
both handles B.
☞ Press levers A on either side and make them lock into place.
☞ Keep levers D on the left and right pressed and pull the lower front window downward.
☞ Release levers D and make them lock into place on either side.
Fig. 124: Closing the front window
A
B
Fig. 125: Closing the front window
A
Fig. 126: Closing the lower front window
D
