BA 50Z3/6003 en – Edition 4.3 * 5003b340.fm 3-101
Operation
Working with the Vario feature
The upper carriage can be rotated to the side with the stabilizer blade for excavating pits.
This ensures increased stability when working on the side opposite the stabilizer blade,
with perfect visibility of the pit.
Improved reach with the Vario feature
• Reach can be improved with the Vario feature.
The attachment can be moved up to the stabilizer blade by repositioning the upper car-
riage to the side opposite the blade.
Fig. 207: Repositioning with the Vario feature
