BA 50Z3/6003 en – Edition 4.3 * 5003b330.fm 3-61
Operation
3.36 Exit through the door (from serial no. AJ02777)
Careful when entering and leaving the cab –
Risk of accidents.
☞ Before exiting the cab, stop and secure the machine
– see chapter 3.18 Parking the machine on page 3-29.
• Lower the boom.
• Stop the engine.
• Remove the ignition key.
• Move control levers 1 and 2 in all directions repeatedly.
Do not use handle B on the control lever base, the outside mirror (option) or its
bracket as a support to ease your entrance or exit from the cab:
☞ Use handles A and footholds on the cab.
When entering or leaving the cab, the door must be locked in the arrester.
– see chapter 3.34 Door on page 3-58.
VDS foothold
☞ Use foothold A.
Fig. 137: Foothold and handle (canopy)
A
Fig. 138: Foothold and handles
A
