Wacker Neuson E05-05 User Manual

6-16 BA 50Z3/6003 en – Edition 4.3 * * 5003b610.fm
Specifications
Main data Model 6003 Vario (option)
A Height 2570 mm (8'-5'') 2684 mm (8'-10'')
B Width 1990 mm (78 in) 1990 mm (78 in)
C Transport length 5800 mm (19'-0'') 5800 mm (19'-0'')
D Max. digging depth (short stick) 3854 mm (12'-8'') 3740 mm (12'-3'')
E Max. digging depth (long stick) 4153 mm (13'-7'') 4040 mm (13'-3'')
F Max. vertical digging depth (short stick) 2855 mm (9'-4'') 2735 mm (8'-12'')
G Max. vertical digging depth (long stick) 3135 mm (10'-3'') 3015 mm (9'-11'')
H Max. digging height (short stick) 5660 mm (18'-7'') 5780 mm (18'-12'')
I Max. digging height (long stick) 5850 mm (19'-2'') 5970 mm (19'-7'')
J Max. tilt height (short stick) 3995 mm (13'-1'') 4110 mm (13'-6'')
K Max. tilt height (long stick) 4185 mm (13'-9'') 4300 mm (14'-1'')
L Max. digging radius (short stick) 6237 mm (20'-6'') 6487
1
/6987
2
mm (21'-3" / 22'-11")
M Max. digging radius (long stick) 6524 mm (21'-5'') 6774
1
/7274
2
mm (22'-3" / 23'-10")
N Max. reach at ground level (short stick) 6122 mm (20'-1'') 6345
1
/6845
2
mm (20'-10"/22'-5")
O Max. reach at ground level (long stick) 6415 mm (21'-1'') 6640
1
/7140
2
mm (21'-9" / 23'-5")
P Min. tail end swivelling radius 1465 mm (58 in) 1465 mm (58 in)
Q Max. boom displacement to bucket centre (right side) 745 mm (29 in) 745 mm (29 in)
R Max. boom displacement to bucket centre (left side) 535 mm (21 in) 535 mm (21 in)
S Max. lift height of stabilizer blade over ground 390 mm (15 in) 390 mm (15 in)
T
Max. scraping depth of stabilizer blade below ground
surface
400 mm (18 in) 400 mm (18 in)
U Running gear length 2500 mm (98 in) 2500 mm (98 in)
V Max. tilting angle of boom to the right 51° 51°
W Max. tilting angle of boom to the left 75° 75°
X Track width 400 mm (16 in) 400 mm (16 in)
Max. breakout force at bucket tooth 39.70 kN (8925 lbf) 39.70 kN (8925 lbf)
Max. tearout force (short stick) 28.10 kN (6317 lbf) 28.10 kN (6317 lbf)
Max. tearout force (long stick) 25.10 kN (5643 lbf) 25.10 kN (5643 lbf)
Max. tail end lateral projection over tracks 470 mm (19 in) 470 mm (19 in)
1. Vario to the rear
2. Vario to the front
