6-18 BA 50Z3/6003 en – Edition 4.3 * * 5003b610.fm
Specifications
Main data Model 6003 triple articulation boom (option)
A Height 2570 mm (8'-5'')
BWidth 1990 mm (78 in)
C Transport length 5260 mm (17'-3'')
D Max. digging depth (short stick) 3872 mm (12'-8'')
E Max. digging depth (long stick) 4174 mm (13'-8'')
F Max. vertical digging depth (short stick) 3218 mm (10'-7'')
G Max. vertical digging depth (long stick) 3497 mm (11'-6")
H Max. digging height (short stick) 6504 mm (21'-4'')
I Max. digging height (long stick) 6747 mm (22'-2'')
J Max. tilt height (short stick) 4746 mm (15'-7'')
K Max. tilt height (long stick) 4990 mm (16'-4'')
L Max. digging radius (short stick) 6604 mm (21'-8'')
M Max. digging radius (long stick) 6894 mm (22'-7'')
N Max. reach at ground level (short stick) 6495 mm (21'-4'')
O Max. reach at ground level (long stick) 6790 mm (22'-3'')
P Min. tail end swivelling radius 1465 mm (58 in)
Q Max. boom displacement to bucket centre (right side) 745 mm (29 in)
R Max. boom displacement to bucket centre (left side) 535 mm (21 in)
S Max. lift height of stabilizer blade over ground 390 mm (15 in)
T Max. scraping depth of stabilizer blade below ground surface 400 mm (18 in)
U Running gear length 2500 mm (98 in)
V Max. tilting angle of boom to the right 51°
W Max. tilting angle of boom to the left 75°
X Track width 400 mm (16 in)
Max. breakout force at bucket tooth 39.70 kN (8925 lbf)
Max. tearout force (short stick) 28.10 kN (6317 lbf)
Max. tearout force (long stick) 25.10 kN (5643 lbf)
Max. tail end lateral projection over tracks 530 mm (21 in)
