Specifications
6.33 Lift capacity table 6003 long stick, triple articulation boom, counterweight (option)
All table indications in kg (lbs) and horizontal position on firm ground without bucket.
If equipped with a bucket or other attachments, lift capacity or tilt load is reduced by bucket
or attachment dead weight.
Calculation basis: according to ISO 10567
The machine’s lift capacity is restricted by the settings of the pressure limiting valves and
the hydraulic system’s stabilizing features.
Neither 75 % of the static tilt load nor 87 % of the hydraulic lift capacity is exceeded.
5.0 m (16'-5") 4.0 m (13'-1") 3.0 m (9'-10")
A
B
Lowered blade Lowered blade Lowered blade Lowered blade
5.0 m
(16'-5")
1335*
(2944*)
1160
(2558)
4.0 m
(13'-1")
1180*
(2602*)
830
(1830)
1175*
(2591*)
875
(1929)
1225*
(2701*)
1225*
(2701*)
3.0 m
(9'-10")
1120*
(2470*)
690
(1521)
1175*
(2591*)
870
(1918)
1330*
(2933*)
1275
(2811)
2.0 (78.7 in)
1090*
(2403*)
615
(1356)
1255*
(2767*)
835
(1841)
1540*
(3396*)
1190
(2624)
2110*
(4653*)
1855
(4090)
1.0 (39.4 in)
1070*
(2359*)
585
(1290)
1340*
(2955*)
785
(1731)
1740*
(3837*)
1090
(2403)
2540*
(5601*)
1625
(3583)
0.0 m
(0.0 in)
1050*
(2315*)
590
(1301)
1370*
(3021*)
750
(1654)
1830*
(4035*)
1015
(2238)
2620*
(5777*)
1500
(3307)
−1.0 m
(−39.4 in)
1010*
(2227*)
640
(1411)
1285*
(2833*)
730
(1610)
1755*
(3870*)
985
(2172)
2430*
(5358*)
1470
(3241)
−2.0 m
(−78.7 in)
915*
(2018*)
755
(1665)
1460*
(3219*)
990
(2183)
2010*
(4432*)
1490
(3285)
Fig. 346: Lift capacity table (model 6003)
max Admissible load on extended stick
A Reach from live ring centre
B Load hook height
* Lift capacity limited by hydraulic system
With the stabilizer blade in driving direction
Without the stabilizer blade, 90° to driving direction
