13.6 SPARE PARTS LIST OF HEATING HOSE DRUM
SPARE PARTS AND ACCESSORIES
POS. ORTDER-NO DESIGNATION
2313 048 Front cover assy.
(pos. 1-7,33,34,36,38)
1 2320 429 Display
2 2307 584 Control panel heat controller
3 9920 123 Washer A3.2 DIN 126 (PA)(4)
4 9903 343 Thread-forming screw
M3x6 DIN 7500 (4)
5 2309 735 Insert tongue
6 9920 104 Washer A4.2 DIN 125 (4)
7 9922 101 External tooth lock washer
8 2311 139 Carbon brush (4)
9 9903 322 Thread-forming screw
M4x10 DIN 7500 (14)
10 9955 041 Cable bushing (2)
11 2312 445 Gasket
12 9990 374 Handle M10
13 2312 295 Cap (2)
14 9920 106 Washer A10.5 DIN 125
15 2312 297 Roller (2)
16 9903 347 Oval head screw M10x20
17 2311 258 Hose guide
2315 901 Hose guide assy. (pos. 13,15,17)
18 9900 106 Hexagon head screw M6x12 DIN933
19 9990 232 Pipe clip
20 2312 296 Roller guide
2316 034 Roller guide assy. (pos. 13,15,20)
21 2311 168 Rear reel shell
22 9910 204 Hexagon nut M6 DIN985(5)
23 2311 167 Front reel shell
24 9900 108 Hexagon head screw M6x20 DIN933 (4)
25 9994 962 Plain bearing
26 2311 002 Reel housing
27 9920 614 Shim ring (2)
28 9922 535 Circlip (2)
29 2311 171 Overheating control
30 2307 585 Heat controller for 230V control unit
31 2306 244 Terminal strip (6-way)
32 2311 150 Swivel joint assy.
33 9921 902 Retaining washer D6 DIN 6799
POS. ORTDER-NO DESIGNATION
34 2311 153 Threaded rod
35 2311 148 Tube assy.
36 9901 319 Threaded insert
37 9906 003 Thread-forming screw
M6x25 DIN 7500 (4)
38 2312 233 Star grip
39 2311 144 End ring
40 2311 143 Insulating ferrule (3)
41 2311 142 Slip ring (3)
42 2309 732 Felt sealing strip
43 9901 114 Setscrew M5x6 DIN 916 (2)
44 2309 733 Heatshrink sleeving (3)
45 9900 743 Socket head cap screw M4x60 DIN 84
A (3)
46 0252 455 Mini raster
47 2311 657 Heating hose assy.
48 0367 561 Double-ended union
49 9984 458 Hose whip
50 9984 590 Hose whip assy.
51 9900 318 Socket head cap screw
M8x20 DIN 912 (2)
52 9920 102 Washer (2)
53 2311 248 Hose reel complete
54 2312 294 Cap
55 9950 212 Terminal strip (3-way)
56 9952 685 Cable coupling with antikink spiral
57 0261 352 Power cord assy.
58 0344 425 Power cable adhesive label
59 2311 145 Bearing
2315 770 Bearing assy. (pos. 39-45,54-59,61-63)
60 9990 866 Rubber cap (2)
61 0341 350 Double-ended union
62 9970 103 Sealing ring
63 2309 734 Heatshrink sleeving
64 2320 474 Protective cap
65 2320 459 Hose whip adhesive label
The number in brackets gives the total quan-
tity of a component in the assembly.
The order number corresponds to one piece.
Therefore, please also specify the quantity
that you require when ordering.
