WAGO 750 Series System Manual

Serie 750, 753 Decommissioning
System manual | Version: 3.0.2 51
8Decommissioning
8.1 Shutting Down
1. Bring the process to a secure stop.
2. Disconnect the respective system component from the power supply.
3. Check if the voltage is isolated.
4. Protect the system component from accidental or unauthorized restart.
5. Switch off any system and/or field supply to the node that is still connected. The or-
der has no effect.
ð The node does not carry any power and the product can be dismounted (8Assem-
bly and Disassembly [}43]).
8.2 Entsorgung und Recycling
Table11: WEEE Mark
Logo Description
Electrical and electronic equipment may not be disposed of with household waste. This also
applies to products without this mark.
Electrical and electronic equipment contain materials and substances that can be harmful
to the environment and health. Electrical and electronic equipment must be disposed of
properly after use. Environmentally friendly disposal benefits health, protects the environ-
ment from harmful substances in electrical and electronic equipment and enables sus-
tainable and efficient use of resources.
• Observe national and local regulations for the disposal of batteries, packaging and
electrical and electronic equipment.
• Clear any data stored on electrical and electronic equipment.
• Remove any batteries or memory cards installed in electrical and electronic equipment.
• Dispose of all types of packaging to ensure a high level of recovery, reuse and recy-
cling.
• Have electrical and electronic equipment sent to a local collection point.
• The guidelines 2006/66/EG, PPWD 2018/852/EU and WEEE 2012/19/EU apply
throughout Europe. National directives and laws may vary.
More information about this topic:8Product-Related Environmental Protection [}26]

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
