9.2 Accessories
Table12: Recommended accessories
Item No. Item Description Item Description
WAGO DIN-Rails
210-1xx DIN-rails Steel bluish, galvanized, chromated;
copper
Buffer
787-8xx Capacitive buffer modules Capacitive buffer modules to bridge
short-term voltage drops or load
fluctuations and to establish an un-
interruptible power supply

WAGO 750 Series Specifications

General

Protection Class	IP20
Bus Couplers	PROFIBUS, CANopen, Ethernet
Modules	Digital Input, Digital Output, Analog Input, Analog Output
Mounting	DIN rail mounting
Voltage Supply	24 V DC (typical)
Communication Protocol	Depends on the bus coupler (e.g., PROFIBUS, CANopen, DeviceNet, Ethernet)
Digital Input Channels	Varies by module (e.g., 8, 16 channels)
Digital Output Channels	Varies by module (e.g., 8, 16 channels)
Analog Input Channels	Varies by module (e.g., 2, 4, 8 channels)
Analog Output Channels	1, 2, 4 channels (depending on module)
Width	12 mm, 24 mm (typical module widths)
Number of Channels	Varies by module type
Current Consumption per Channel	Varies by module type
