WP1624
Firewood Processor
Operating Instructions
47
00363
7.10 Log Lifter Option
(If equipped)
The log lifter option provides a method for loading logs onto the
live deck from ground level.
If equipped, an additional control valve lever is provided on the
far right-hand side of the main control valve.
• Push the lever forward to lower the live deck.
• Pull the lever back to raise the deck.
The log lifter may be used as a deck extension.
Raise it to horizontal to hold extra logs.
00401
Fig. 70 – Log Lifter Control Valve Lever
Fig. 71 – Log Lifter
