Operating Instructions
WP1624
Firewood Processor
44
7.8 Splitting
Conveyor Start-up (if equipped)
• If equipped with the integrated conveyor, pull the conveyor
control lever back towards the operator.
00406
Fig. 61 – Conveyor Control Lever
Wedge Height, Adjusting
The control lever is on the upper part of the control panel, to the
far left-hand end. Wedge height can be quickly adjusted while
working.
A 6-way splitting wedge is available as an
accessory. To change the wedge, see procedure on
page 45.
• Center wedge height on the log. Raise or lower depending
on log size.
00405
Fig. 62 – Adjust Wedge Height
CAUTION!
Risk of pinching or crushing
hazard! Never reach into the
splitting cradle to reposition a log.
Use a log peavey, hookaroon or
another tool.
W043
Use the Hookaroon when repositioning logs. Use it to extend
reach and keeps hands away from machinery.
00294
Fig. 63 – Hookaroon
