Machine Set-up
WP1624
Firewood Processor
28
5.3 Live Deck, Lowering with Log
Lifter Shelf
(If equipped)
The live deck is lowered with the log lifter cylinder. A decal on
the side of the live deck explains the steps.
• Make sure the machine is completely setup for operation.
• Start the engine. Leave the throttle setting at idle.
IMPORTANT! Leave the engine throttle at idle speed for
better control.
00416
Fig. 17 – Log Lifter Shelf Option
00421
Fig. 18 – Log Lifter Shelf Control Valve Lever
A
A
A
B AB
B
B
C,D
2X
2X
C,D
