122 Creating PowerLine Methods
Accessing the Detector Tables Screen
1. Press the Program Table function key to display the Program Gradient screen (see
Figure 6-5).
2. Press the Next Table screen key to display the Program Event screen (see
Figure 6-9).
3. Press the Next Table screen key. The Detector Tables screen appears (Figure 6-12).
Figure 6-12 Detector Tables Screen
In addition to the detector tables parameters, there are five active screen keys on the
Detector Tables screen. These screen keys have the functions described in Table 6-4.
Table 6-4 Detector Table Screen Keys
Key Function
Next Table Cycles through the Program Gradient screen, Program
Event screen, and back to the Detector Tables screen.
Clear Line Clears the line on which the cursor currently resides. The
line remains in permanent memory.
Clear Table Clears the entire table currently displayed on the screen
and returns the initial conditions line to default status. The
table remains in permanent memory until you save a new
table.
