Preparing the column compartments 21
b. Using a small screwdriver, gently pry out the active preheater
retainer, and remove it from the column compartment.
8. Remove any solvent lines routed behind the column heater door.
9. Detach the leak sensor connector from the front of the sample manager,
if fitted.
10. Remove the TORX screw from the right-hand side of the column heater,
just behind the eCord receptacle.
Gently compress
retainer here
TORX screw
eCord
receptacle
