Waves eMotion LV1 Classic User Guide | Chapter 1: Mixer
Window Window
1
48V Phantom Power: Activates the microphone preamp 48V phantom power. Stereo channels have
independent L/R 48v phantom controls. Options: On/Off; default: Off
Preamp/Local Select: Preamp mode adjusts the preamp’s analog gain, just like the preamp gain control
in the device’s control panel. Local is a digital gain stage that always delivers the user’s requested input
gain, regardless of the preamp’s analog gain setting. Refer to refer to Channel >Input Sections >.
2
Preamp Analog Gain Control: Adjusts the analog level of an I/O device preamp. Knob position is displayed in
the value box and with a blue ring around the knob. Stereo channels have independent L/R input controls.
Preamp control range varies depending on the I/O, and adjustments made in the I/O control panel are
reflected here.
If there is no preamp on the channel, this section does not appear, and the only input control available is
Channel Trim.
ON THE FADER BANK
Use a channel’s encoder knob to control the preamp and adjust channel trim. When the encoder knobs are set
to control gain, they automatically map to the channel input’s preamp-Gain or local-VGain. If there is no
preamp, the encoder knobs control the channel trim. Gain value is shown in the scribble strip.
Input Polarity Reverse: Reverses the polarity of an input channel. Each channel of a stereo input can be
controlled separately. Options: On/Off; default: Off
Channel Trim: Trims channel input level digitally. Stereo channels/busses have independent left and right trim
controls that can be linked. Range: -144 dB to +10 dB
