WBOX Technologies 0E-4CHNVR2TB User Manual

3 Operation Instruction
Network Video Recorder(NVR)
User Manual
10
Issue V1.0 (2018-05-11)
Table 3-3 Elements of the real panel of 0E-16CHNVR2T & 0E-16CHNVR4T
NO.
Name
Description
1
PoE network
interface
PoE network interfaces
2
LAN
RJ45 10 /100/1000 Mbps adaptive
Ethernet interface
3
Reset
Factory reset button
4
Line In/ Line Out
Audio input/ Audio output
5
VGA
Video output interface
6
HD-OUT
7
USB 3.0
Connect to mobile storage devices
8
Alarm In/Out
2 alarm input, 2 alarm output
9
Ground screw
Safe ground screw of the device
10
Power switch
--
11
Power interface
AC 110V/220V power input interface of the
device
3.3 Startup
Before starting the NVR, ensure that the NVR is connected to a power supply.
When the NVR is connected to a power supply, it starts automatically upon the initial
power-on.

Ensure that a power supply is connected to the NVR correctly.

Before starting the NVR, ensure that a monitor is connected to the HDMI or VGA
interface of the NVR correctly.

The NVR may not operate normally when a power supply exception occurs, likely
causing damage to the NVR in serious conditions. In such a circumstance, you are
advised to use a regulated power supply.
When the NVR is started, the power indicator becomes steady on and the NVR starts a
self-test and displays the test result on the screen, as shown in Figure 3-4.The startup
process takes about 2 minutes.
