WBOX Technologies 0E-4CHNVR2TB - External Device; Display Screen

Setting
Network Video Recorder(NVR)
User Manual
Issue V1.0 (2018-05-11)
69
3. Click OK. The system saves the settings. And the name listed in the black (white)
list.
4.

Select a name in the list and click to delete the name from the list.

Select a name in the list and click to edit the name in the list.

Only one rule type is available, and the last rule type set is efficient.
8.7 External Device
8.7.1 Display screen
Configure the external display device connect to NVR.
Step 1 Choose Setting >NVR Setup>External Device>Display screen,
The display screen interface is displayed, as shown in Figure 8-30.
Figure 8-30 Display screen interface
Step 2 Select a major resolution from the drop-down list box. The major resolution includes:
1080P, 720P, 1024*768, 3840*2160.
Step 3 Click the button on to enable the minor screen.
Step 4 Select a minor resolution from the drop-down list box. The minor resolution includes:
1080P, 720P, 1024*768, 3840*2160.
Step 5 Click Apply, the “Be sure to modify, the device will restart” dialog box prompt.
