The iPump model number is structured as follows to describe the options on
each iPump:
IP - ABC - D - EF - G - H - JJ - K
Table 1: iPump Options Key
Model Number
Position
Option Name Designator Description
IP This prefix simply indicates that the unit is an iPump.
A Input Type 1 - DVB RF Input
2 - ASI Input
B First Decoder Type
(middle slot)
0 - No decoder
1 - Basic decoder
2 - professional 4:2:0 decoder with analog outputs
3 - professional 4:2:2 decoder with analog outputs
4 - professional 4:2:2 decoder with digital outputs
5 - professional audio output
C Second Decoder Type
(bottom slot)
0 - No second decoder
1 - Basic decoder
2 - professional 4:2:0 decoder with analog outputs
3 - professional 4:2:2 decoder with analog outputs
4 - professional 4:2:2 decoder with digital outputs
5 - professional audio output
D Disk Storage Capacity 1 - 40 Gigabytes
2 - 80 Gigabytes
3 - 120 Gigabytes
4 - 160 Gigabytes
5 - 200 Gigabytes
6 - 240 Gigabytes
E Contact Closure Module
Type
1 - Alarm and contact closure in and out on DB-9
2 - Alarm and contact closure in and out on DB-9, plus
RJ-11 internal modem
F Reserved
G Reserved
HLine Cord
(power connector)
1 - U.S.
2 - U.K.
3 - Europe
4 - Australia
JJ Reserved
K Other 0 - none
1 - Auxiliary audio
