iPump User’s Manual
wegener.com 11 800009-01 Rev. A
1.3 iPump Specifications
Table 2: Technical Specifications
Characteristic Specification
RF
Input Frequency tuning via front panel control or COMPEL
Input FrequencyRange 950 to 2150 MHz
Input Impedance 75 ohms
LNB Power 250 mA max, 22 kHz tone control
vertical polarity: 12.4 to 14.0 VDC
horizontal polarity: 17.0 to 19.0 VDC
Tuning Resolution 1 kHz
Modulation QPSK
Transport Rate Range 2.0 to 45 Msps
VIDEO COMPRESSION
Video Data Rate up to 15 Mbps per service
Compression Type MPEG 4:2:0 or 4:2:2
Horizontal Resolution 720, 704, 640, 544, 480, 352
Vertical Resolution 480 lines @ 30 Hz (NTSC)
240 lines @ 30 Hz (NTSC)
576 lines @ 25 Hz (PAL)
288 lines @ 25 Hz (PAL)
VIDEO OUTPUT
Video Format NTSC/PAL composite and SDI (with embedded audio)
Output Level 1 Vpp ± 5%
Output Impedance 75 ohms
AUDIO COMPRESSION
Compression Type MPEG Layer II
Data Rate 64 to 384 kbps
Output Modes Supported Mono, Dual Mono, Joint Stereo
