iPump User’s Manual
wegener.com 19 800009-01 Rev. A
Alarm
Connector
Details
The DB-9 alarm connector has the following pin functions:
Table 4: iPump Connector Details
Designation
Connector
Type
Signal Description Additional Information
RF IN female Type F 950 to 2150 MHz RF carrier
from antenna LNB
A extension cable is shipped already
attached to the RF IN port to allow
easier access for attaching your RF
input.
ASI IN female BNC ASI input signal Only on iPumps with the ASI input
option.
AUDIO 1/8-inch stereo
jack
Audio output A 1/8-to-RCA adapter is shipped
with your iPump (one for each active
audio decoder).
AUX AUDIO 1/8-inch stereo
jack
Audio output Can be "slaved" to decoder 1 or
decoder 2
VIDEO BNC S-video, video output A SVD-to-RCA adapter is shipped
with your iPump. Units equipped
with the optional, professional 4:2:2
decoders will have a female BNC
connector.
LAN female RJ-45 10/100baseT Ethernet Autosensing; see pinout detail
in
Table 6: iPump LAN Con-
nector Pin Functions on
page 20
CONTACT
CLOSURE/
ALARM
male DB-9 Contact closure/opening in and
out
See pinout detail in
Table 5:
iPump Alarm Connector Pin
Functions on page 19
POWER Male IEC recep-
tacle
100-to-120 Vac @60 Hz or
200-to-240 Vac @ 50 Hz
Autoswitching
Table 5: iPump Alarm Connector Pin Functions
Pin Number Function
1 Alarm common
2 Alarm Normally Open
3 Contact Closure Out Common
4 No Connection
5 Contact Closure Input
