Weidmüller AC SMART VALUE Socket User Manual

Networking and conguring the EV charging box
91
Operating instructions – AC SMART
Managing RFID tags
RFID tags can be registered, authorised, blocked and deleted.
To register a new RFID tag, proceed as follows:
► Click RFID.
► In the Learn new tageld,clickStart.
► Hold the RFID tag in front of the interaction area of the EV charging box
within 60 seconds.
Afterregistrationiscomplete,youwillhereaconrmationsignal.
► Click Refresh.
TheIDofthedetectedRFIDtagisdisplayedintheeld Last found tag and
in the tag list. The status Accepted is displayed in the Statusselectioneld.
► If you want to assign the ID a name, enter it in the list.
► If you want to block a registered RFID tag, change its status in the Status
selectioneld.
► Click Save.
To delete a registered RFID tag, you can execute an unlearn process or
delete the tag from the tag list.
Unlearn Tag
► Click RFID.
► In the Unlearn tageld,clickStart.
► Hold the RFID tag in front of the interaction area of the EV charging box
within 60 seconds.
Afterdeletioniscomplete,youwillhereaconrmationsignal.
► Click Refresh.
The RFID tag is no longer displayed in the tag list.
Deleting from the tag list
► Click Delete behind the RFID tag you want to delete.
The RFID tag is no longer displayed in the tag list.
Conguring digital inputs
You must be logged in as an Admin. Electrician only!
Youcancongurethedigitalinputsforthefollowingfunctions:
– Release charging process via external switching device (charging
authorisation)
– Restricting the charging current (current limitation)
If the digital input is active, the maximum charging current according to the
setting is made available. When the setting is at 100%, the maximum charg-
ing current is used; when the setting is at 0%, there is no charging at all.
► Click Cong/Input.
► Change the function of the desired digital input.
► Activate the function.
► Activate Input monitoring if necessary.
► Click Save.
You can view the current switching status of the digital inputs in the Status
eld.Ifthereisasignalataninput,atickmarkisaddedtothestatuseld.
Prerequisite
