Installation
21
19
20
23
22
24
Figure 3 Connections
17 Power switch
18 Power connection jack
19 Slot for SD card
20 2 USB master ports for keyboard, scanner, USB memory stick, Bluetooth adapter, service key or WiFi
stick
21 USB full-speed slave port
22 Ethernet 10/100 Base-T
23 Serial RS-232 port
24 USB master port for keyboard, scanner, USB memory stick, Bluetooth adapter, service key or WiFi stick
