Weidmüller THM MultiMark User Manual

54 2599430000/00/04.2019
Fault Correction
7.3 Problem Solution
Problem Cause Remedy
Transfer ribbon
creases
Transferribbondeectionnotadjusted Setting the feed path of the transfer rib-
bon
→„4.4 Setting the Feed Path of the
Transfer Ribbon“ on page 47
Transfer ribbon too wide Use a transfer ribbon slightly wider than
the width of label.
Print image has
smears or voids
Printhead is dirty Clean the printhead
→„6.3 Cleaning the Printhead“ on page
49
Temperature too high Decrease temperature via software.
Unsuitable combination of labels and
transfer ribbon
Usedi󰀨erenttypeofribbon.
Printer does not
stop after transfer
ribbon runs out
Thermal printing is chosen in the soft-
ware
Change to thermal transfer printing.
Printer prints a
sequence of char-
acters instead of the
label format
Printer is in ASCII dump mode Cancel the ASCII dump mode.
Printer transports
label media, but
transfer ribbon does
not move
Transfer ribbon incorrectly inserted. Check and, if necessary, correct the
transfer ribbon web and the orientation of
the label side.
Unsuitable combination of labels and
transfer ribbon
Usedi󰀨erenttypeofribbon.
Printer only prints
each second label
Setting of the size in the software is too
large.
Change the size in the software.
Vertical white lines
in the print image
Printhead is dirty Clean the printhead
→„6.3 Cleaning the Printhead“ on page
49
Printhead is defective (failure of heat
elements)
Change the printhead.
→ServiceManual
Horizontal white
lines in the print
Printer is used with the backfeed >
smartinthecutorpeel-o󰀨mode
Set the backfeed > always in the
setup.
→CongurationManual.
Print image is ir-
regular, one side is
lighter
Printhead is dirty Clean the printhead
→„6.3 Cleaning the Printhead“ on page
49
Table 7 Problem solution
