42 2599430000/00/04.2019
Touchscreen display
Intheheadlineseveralinformationaredisplayedaswidgetsdependingontheconguration:
Figure 6 Widgets in the start screen
Symbol Function
Displays the current data transfer in the form of a falling drop.
The Save data streamfunctionisactive→Congurationmanual
Allreceiveddataarestoredina.lblle.
Warningribbonend→Congurationmanual
The remaining diameter of the ribbon supply roll undershoots the set value.
SD card installed
USB memory installed
gray: Bluetooth adapter installed, white: Bluetooth connection active
WiFi connection active
The WiFi strength is displayed by the number of white arcs.
Ethernet connection active
USB connection active
abc program active
Clock time
Table 3 Widgets in the start screen
