WEIHONG Lambda 5S Series User Manual

上海维宏电子科技股份有限公司
Weihong Electronic Technology Co., Ltd.
- 100 - Specialized, Concentrated, Focused
5.4.2.12 Parameter Setting of SANYO PY Servo Driver
Para.
No.
Abbr.
Name
Standard
Value
Setting
Range
Unit
Remark
1-2
EGER
Electronic
gear ratio
4/1
1/32767
to
32767/1
Depend on the specific
encoder resolution. The
formula of electronic gear ratio
of servo driver is as below:
Electronic gear ratio numerator
=mechanical deceleration ratio
× 4× pulse No. per encoder
circle;
Electronic gear ratio
denominator = (screw pitch /
pulse equivalent)
E.G. In Weihong system, the
default pulse equivalent is
0.001mm/p, screw pitch is
5mm, pulse number per
encoder circle is 2000 and
deceleration ratio is 1:1; so the
numerator of the electronic
gear ratio is 8, and the
denominator is 5. (Select an
incremental type encoder)
1-16
MENP
Pulse amount of the motor
encoder
1. Set the pulse amount of
the motor encoder;
2. Standard configuration
of the encoder pulse No.
is as below.
Incremental encoder
omitting wiring: --2000P/R
Absolute
encoder:--2048P/R
500
to
65535
P/R
2-0
PMOD
Pulse format of position command:
Our system uses: direction + pulse format, the parameters are shown as
following:
