 For a Lambda 4S/5S series CNC system, when PC logical data or physical connection interrupted,
the IO ports on the controller and the extended terminal board maintain their status.
1.6 Configuration
1.6.1 Lambda 3S/3L Series CNC System
 One communication card (PM85A or PM95A);
 One Lambda 3S/3L series controller;
 One DB9M/F cable (Cable length customizable);
 Cables (DB15) connected to stepping drivers (Configured according to actual situations);
 One NcStudio motion control software CD (Not required if software customized);
 One NK-MPG-06 handwheel (Optional).
1.6.2 Lambda 4S/5S Series CNC System
 One communication card (PM85A or PM95A) or one NC65A/65B or NK300BX host;
 One Lambda 4S/5S series controller;
 One NcStudio motion control software CD (Not required if software customized);
 One DB9M/F cable (Cable length customizable);
 One handwheel (Optional, including NK-MPG-06, aviation plug handwheel NK-MPG-09 and
EHDW-DA5S-1M).
CAUTION
1) For the info related to Lambda 4S controller used together with NK300BX host, please refer to NK300BX
Integrated CNC System Manufacturers’ Manual.
2) The configuration specified in Section 1.6 is the standard one. Please make sure the configuration according
to the delivery note.
