34 EN MEDUMAT Standard
2
WM 68071 05/2021
3 Description
No. Designation Description
1
FlowCheck sensor connection line
with MEDUtrigger
Connects MEDUtrigger and the FlowCheck sensor to
the device.
2 FlowCheck sensor connection line Connects the FlowCheck sensor to the device.
3 Inhalation adapter Facilitates inhalation.
4 Ventilation mask Connects the breathing circuit to the patient.
5 Hygiene filter
Protects the device from viral and bacterial
contamination.
6 etCO
2
/O
2
nasal cannula
Allows oxygen inhalation via an external flow source
with simultaneous CO
2
measurement via the device
(see 4.4.7, p. 62)
7 Breathing circuit
Administers the gas for inspiration to the patient via a
mask or endotracheal tube. There are three types of
breathing circuits:
• Reusable breathing circuit (see 3.5.2, p. 35)
• Disposable breathing circuit (see 3.5.2, p. 35)
• Disposable breathing circuit with reduced dead
space (see 3.5.4, p. 38)
8 Battery
Facilitates mobile power supply and can be replaced
if necessary.
9 Testing bag Simulates a ventilated patient during a function check.
10 Connection line of MEDUtrigger Connects MEDUtrigger to the device.
11 MEDUtrigger Is used to manually trigger mechanical breaths.
