7 Control electronics
Training manual Convotherm 4 100
Item Name
DID PIN
PIN assignment
-5B6:1
19
Grease filter float switch (SIGNAL)
-5B2:OUT
(1)
20
Collector flow rate (SGND)
-5B2:OUT
(1)
21
Cleaning-fluid flow rate (SIGNAL)
-5B2:VCC
(3)
22
Cleaning-fluid flow rate (PLUS)
X30
Variable frequency drive 2 -3T6:RJ45 MODBUS motor 2
X31
Spare outputs
n/a
1
SPARE output 1 (SIGNAL)
n/a
2
SPARE output 1 (PLUS)
n/a
3
SPARE output 2 (SIGNAL)
n/a
4
SPARE output 2 (PLUS)
X32
Signal tower
-
1
GND
-
2
Buzzer (SIGNAL)
-
3
RED (SIGNAL)
-
4
YELLOW (SIGNAL)
-
5
GREEN (SIGNAL)
X33
Water treatment
1
SIGNAL
2
GND
X34 AC phase input (after main
contactor)
X35
Appliance ON/OFF switch
-2Q0:1
1
ON/OFF appliance switch (NO) >> LINE MNTR IN
-2Q0:2
2 ON/OFF appliance switch (NC) >> MAIN SW OFF
IN
-2Q0:3
3 ON/OFF appliance switch (COM) >> PRE LINE
PHASE IN
X36
Smoker
-3E:1
1
SIGNAL
-3E:2
2
NEUTRAL
X37
Sicotronic
-X37:A
1
SICOTRONIC (A) >> MAIN CONT OUT
-X37:B
2
SICOTRONIC (B) >> SICOTRONIC RLY OUT
-X37:C
3
SICOTRONIC (C) >> SICOTRON OPTO IN
-X37:D
4
SICOTRONIC (D) >> PRE LINE NEUTRAL
