Welbilt Convotherm 4 - Testing Steam-Generation Injection at the Injection Unit

9 Servicing / Cleaning
Training manual Convotherm 4 139
9.3.2 Testing steam-generation injection at the injection unit
Component
Illustration Name
Injection unit
Tools required
None
Requirements
Check that the following requirements have been met:
 The appliance is in the Steam main cooking program.
 The left-hand side panel has been removed.
Testing the water injection system
1.a
easyDial:
Select the Steam main cooking program at 100°, or select the
Service value d4.
1.b
easyTouch:
Select the Steam main cooking program at 100°, or press the
'water-injection pressure switch' button under 'I/O' - 'Digital
outputs' in the Service menu.
