4 Operating principles
Training manual Convotherm 4 45
4.5 Waste-water cooling
Item Name Function
1
Flowmeter Monitors the water flow rates for the collector
2
CS-chamber drainage pump Drains the CS chamber in the collector (system is opened)
3
Circulation pump Used for cleaning (recirculates the cleaning solution)
4
Drain probe (5B3) Measures the waste-water temperature
5
Dual solenoid valve Hard-water supply
