2 For your safety
Training manual Convotherm 4 22
Item Safety device Function Check
6 Suction panel in cooking
chamber; can only be
removed using a tool
Prevents access to the moving
fan and ensures good heat
distribution
See 'Removing and fitting the
suction panel' in the user manual
for further details
7 For floor-standing units:
Built-in
preheat bridge in appli-
ance door
Prevents scalding from escaping
steam when the loading trolley is
not in the appliance during
preheating
8
(no picture)
Magnetic door switch:
Electric door sensor for
appliance door
Switches off the fan and heater
when the appliance door is
opened, so that the fan stops
rotating within a few seconds
Check magnetic door switch at
low temperature:
Action:
 Open the appliance door fully
 Press Start
Result:
Motor must not start up
9
(no picture)
Forced rinsing after
power failure in case
cleaning agent was left in
the appliance
Re-starts the ConvoClean /
ConvoClean+ fully automatic
oven cleaning process in a
defined state after power failure
This test is a software function.
There is no need for the user to
perform a test
10
(no picture)
Spray-guard
 Stops distribution of the clean-
ing fluid during the ConvoClean
/ ConvoClean+ fully automatic
oven cleaning process if the
appliance door is opened
 Prompt to close the appliance
door
Test is a software function
11
(no picture)
Main gas valve
Switches off if temperature too
high or gas fails to ignite.
12
(installed by
customer)
Disconnection device
Installed by the customer close to
the appliance; easily visible and
accessible, 3-pole action, mini-
mum contact separation 3 mm.
Used to disconnect the appliance
from the power supply during
cleaning, repair and servicing
work and in case of danger
Action:
 Trip the disconnection device
 Check at the X10 terminal strip
on the appliance that none of
the three phases carry a live
voltage
13
(installed by
customer)
For gas appliances:
Gas shut-off device
Installed by customer close to
appliance in easily accessible
position and clearly labeled.
Used to disconnect the appliance
from the gas supply during
cleaning, repair and servicing
work and in case of danger
Action:
 Close gas shut-off device
 Check that the appliance is
isolated from the gas supply
