26 Overview Welch Allyn CP 100 and CP 200 Electrocardiograph
MMCSDTEST.EXE: Used to test the SD memory card write/read function of the unit. Can also be used to test an SD memory card
for problems.
GO: Starts the SD memory card test by pressing “G”
STOP: Stops the SD memory card test by pressing “S”
ERASE ALL: Erases all files written by this tester by pressing “E”
Card Present: If checked the unit detects the SD memory card inserted.
Write Protect: If checked the unit detects the lock is enabled on the SD memory card.
Pulse: Flashes when test is active
Note: Once the test is started it runs continuously. Press the “S” key to stop the test.
NORMANDY.EXE: Used to return to the ECG program.
NORMTESTER.EXE Strictly used for development purposes.
PPPTEST.EXE Strictly used for development purposes.
PPPTEST2.EXE Used to see battery and charger status/state. There are a number of selections on this screen. Listed below
are the most commonly used functions. To activate a selection press the letter that coincides with the
selection.
Real-time: Activates a real-time monitoring of the readings from the battery circuit.
Battery Voltage: Unplugged from AC this reflects the Voltage of the battery in millivolts; plugged into
AC this reflects the charge voltage in millivolts.
Fast charge = 6800 – 7300
Trickle charge = 6300 – 6800
Battery Current: Indicates charge current in mA when charger is on.
Charger State: Indicates if charge circuit is on or off
Charge State: Indicates if the Fast Charge is on or off
Fast Charge On: Turns fast charge on. If battery is fully charged the sensing circuit can work against
you. It only changes the reading for a brief second before switching back.
Fast Charge Off: Turns fast charge off.
Charger On: Turns charger on when plugged into AC.
Charger Off: Turns charger off.
Function Description
