Service Manual CP 100 and CP 200 Electrocardiograph 21
Print Log
CP 100 Service Info Screen
Procedure Figure 21. CP 100 “UserLogin” Screen
1. Power ON unit.
2. Press Menu key.
3. Choose System Setting > Device Info > Service Info
The “UserLogin” screen appears. See Figure 21.
Use the “Arrow” keys to move the cursor from field to field.
Enter the following:
User ID: Service (case sensitive)
Password:normser (case sensitive)
4. Highlight “Done” using the down arrow key.
5. Press “Enter” key.
The “Service Info” screen appears. See Figure 22
Figure 22. CP 100 “Service Info” Screen
Caution These printouts can be very long. Only use the printouts if necessary.
To stop the printouts press Stop/Cancel.
User Login
User ID
Password
Done
9:17AM Mar 16 05
9:17AM Mar 16 05
Service Info
1. Print Log
2. Battery Life Test
3. Printer Test
4. Export Files
5. Import Files
6. Delete Files
7. Serial Number
7. Lead Off Thershold
8. Service Tests
0. Previous Menus
Function Description
Figure 23. “Print Log” Screen
Print Events: This prints all events stored in the unit in descending
order by date and time. Used for development of the
software. Has no Service value.
Print Errors: This prints any errors that occurred in the unit, in
descending order by date and time, during normal
operation. This can be valuable to use when the end-
user says he/she has been having problems.
Print All: This prints the Print Events and Print Errors as
described above.
9:17AM Mar 16 05
1.Print Events
2.Print Errors
3.Print All
0.Previous Menus
Print Log
To Next Page
