20 Overview Welch Allyn CP 100 and CP 200 Electrocardiograph
CP 100 and CP 200 Electrocardiograph
Service Menus
Entering the Service Info Screen
This menu is password protected and only Welch Allyn Authorized Technician can access
the Service Menus,)
CP 200 Service Info Screen
Procedure Figure 19. CP 200 “User Login”
1. Power ON unit.
2. Press Menu key.
3. Choose System Setting> Device Info> Service Info
The “UserLogin” screen appears. See Figure 19.
Use the “Tab” or “Arrow” keys to move the cursor from field to field.
Enter the following:
User ID: Service (case sensitive)
Password:normser (case sensitive)
4. Press “Done” using the softkey. Do not use the“Enter” key.
The “Service Info” screen appears see Figure 20
Figure 20. CP 200 “Service Info” Screen
9:17AM Mar 16 05
UserLogin
User ID
Password
Change
Password
Cancel
Done
Enter valid user ID and password
9:17AM Mar 16 05
1.Print Log
2.Battery Life Test
3.Printer Test
4.Export Files
5.Import Files
6. Delete Files
7.Serial Number
8.Lead Off Thershold
9.Service Tests
A LCD Test
0.Previous Menus
Service Info
