22 Overview Welch Allyn CP 100 and CP 200 Electrocardiograph
Battery Life Test
This displays the percentage of battery life remaining on the battery, based on the number
of charges it has incurred. This percentage approximates the life left in the battery based
on this information.
Printer Test
Caution Only reset when the battery has been replaced and charged for at
least 12hrs continuously.
Function Description
Figure 24. “Battery Life Test” Screen
Reset Resets the battery life to 100%. This is used only
when the battery has been replaced
Reset Pages Resets page count for the number of prints made on
the printer. Should only be reset when print head has
been replaced.
9:17AM Mar 16 05
Battery Life Test
Battery Life Remaining: 99%
Reset
Reset
Pages
Exit
Function Description
Figure 25. Printer Test” Screen
Test Page Prints a test page which repeats until the “Cancel”
button is pressed. Refer to Functional Verification test
for explanation. See Printer Test (page 35).
Ramp Test Prints a one page ramp test. Refer to Functional
Verification test for explanation. See Printer Test
(page 35).
9:17AM Mar 16 05
Printer Test
Select a print test
Test Page
Ramp
Page
Exit
