Welch Allyn CP 100 Service Manual

10 Overview Welch Allyn CP 100 and CP 200 Electrocardiograph
Product Configurations
Model numbers for the configurations are as follows:
Recommended Service Intervals
Model Number Description
CP 1 CP 100 Electrocardiograph
CP 1A CP 100 Electrocardiograph w/Interpretation
CP 2 CP 200 Electrocardiograph
CP 2A CP 200 Electrocardiograph w/Interpretation
CP 2S CP 200 Electrocardiograph w/Spirometry
CP 2AS CP 200 Electrocardiograph w/Interpretation & Spirometry
Interval or Condition Action Recommended Procedure
Every 6 – 24 months (per
hospital protocols)
Complete Functional test Functional Verification (page 29)
Battery does not hold a charge Check battery capacity
Replace battery
Battery Accuracy Test (page 31)
Replacing the Battery or Fuse (page 58)
Unit has been dropped or
otherwise damaged
Complete Functional test Functional Verification (page 29)
Unit malfunctioning Complete Functional test Functional Verification (page 29)
Unit does not pass Functional
Verification
Troubleshooting and repair followed by functional test
Return to authorized service center
Troubleshooting (page 41)
Disassembly and Repair Procedures (page
47)
Functional Verification (page 29)
Returning Products (page 9)
