30 Functional Verification Welch Allyn CP 100 and CP 200 Electrocardiograph
Functional Verification Overview
This section describes the procedure for a complete functional test to support
recommended preventive-maintenance schedules.
A checklist of the functional tests is provided on page 40. It is recommended that you
print a copy of the checklist each time you perform the functional verification procedure,
so you can record and save the test results. If the electrocardiograph ever requires
service, the records of test results often facilitate troubleshooting.
Functional verification does not require opening the device case.
Full Functional Check
Whenever the electrocardiograph is serviced or problems are suspected, Welch Allyn
recommends a Functional Check.
Equipment Required
Operating/Non-Printing Mode Current Test
When the unit is powered on, the AC is disconnected and the LCD on, the unit’s current
is:
1. Unplug unit from line power
2. Connect a DC power supply, adjusted for 6.4V DC ± .05, in place of the battery.
3. Verify the current draw is within limits as indicated for unit after powering the unit up.
WARNING Only qualified service personnel should perform a full functional
checkout procedure.
Commercially Available General-purpose/Medical Test Equipment
Item Manufacturer
Power Supply Variable, 0 – 8 VDC, 5.0A
(minimum), with voltage and current indicators
AC withstand voltage (hi-pot) tester Associated Research 3605 or equivalent
Electrical Safety Analyzer w/ECG Fluke DNI 232D or equivalent
Computer PIII or better, CardioPerfect installed, available USB port
SD Memory Card 64Mb or Greater
USB Cable A – A type (WA P/N 401435)
Spirometry Dongle Serial Version (W/A P/N 703552)
CP 100 Current CP 200 Current
125 to 250 mA @ 6.4V DC ± .05 675 to 825 mA @ 6.4V DC ± .05
