Westomatic GF Robimat XM - 2.1.2 Sliding Door Unit - Telescopic Slide-out Unit

11
Construction and Features
704 67 020 00 _ 111
OPERATING INSTRUCTIONSGF Robimat XL / XM

1
2
3
4
5
6
7
8
9
10
11
12
13
1 Control board (VMC)
2 Power supply unit
3 Coin insert channel
4 Service keypad
5 Product delivery unit
6 Cashbox
7 Cashbox holder
8 Coin return channel
9 Bracket for coin mechanism
10 Coin mechanism (optional)
11 Coin refund motor
12 Machine mains plug
13 Chiller unit plug
