32
Cleaning and maintenance
704 67 020 00 _ 111
GF Robimat XL / XM
OPERATING INSTRUCTIONS
max. 10°
Basket removed
Release button
Hooks
Alignment guidance!
2
1
3
The product basket can be removed for cleaning. It can be cleaned in the dishwasher at max. 65°C.
Release the two unlocking hooks and pull the basket slightly
towards the right. Then unhook the basket and take it out.
• Unfold the bearing for toothed wheel pendulum by hand.
• Insert the basket into the holder in a slightly slanted position (approx. 10°).
• Push the basket to the left so that the hooks snap into the notch correctly.
• Finally, swing the basket back in and push it upwards so that the unlocking buttons can be heard clicking into
place ("click").
• Malfunctions will occur if the product basket has not clipped in correctly.
Gear wheel assembly
