Installation and commissioning
704 67 020 00 _ 111
OPERATING INSTRUCTIONSGF Robimat XL / XM
F2
The following ne adjustment must still be made once the machine has been levelled:
• Screw adjustable foot A inwards until the machine rocks over axis B - C. Press several times on the corner at F2
to check if the machine rocks.
• Exert strong pressure on the corner at F2 while manually unscrewing foot A until it touches the oor.
• Finally, using a size 24 spanner, make a ¼ to ½ turn to foot A. This results in less weight load on foot A than on
the other feet.
Consequently the machine does not wobble on the corner, the machine door does not drag and the door contact
switch works correctly.
