Machine control board, Software
704 67 020 00 _ 111
GF Robimat XL / XM
OPERATING INSTRUCTIONS
XY COL P
01 101 1
X Limit switch top left (X -) Lift arm not in zero position (left) Lift arm in zero position
Y Light barrier bracket zero position Product basket not in zero
position (down)
Product basket in zero position
C Shutter in closed position (C -
closed)
Shutter not closed Shutter closed
O Shutter in opened position (O -
opened)
Shutter not opened Shutter completely opened
L Locking mechanism of the shutter
(L - locked)
Locking mechanism opened, i.
e. shutter can open
Locking mechanism engaged,
i. e. the shutter cannot be
opened
P Light barrier in product basket
(P - product basket)
No bottle or can in basket
detected
Bottle or can in basket detected
X
Y
[
The illumination for the machine can be switched on and o here.
The status of limit switches and light barriers is displayed by 0 and 1.
If a limit switch is actuated manually, 0 will change to 1, which proves that it functions
correctly.
Here the basket can be moved and stopped at every single product container to collect a
product, and then moved with the product back to the zero position.
This is the menu where you can visually check the product transfer into the basket.
[ Oset is the dierence to 0 caused by mechanical tolerances. X and Y directions can be
set separately.
The maximum displacement of the X and Y directions are inuenced by scale due to the
belt expanding (i.e. age, temperature, wear, length).
If, for example, the toothed wheel of the product basket goes to the top product shelf
(Y direction) 2 mm too low, Y Scale must be set to + 2.0 mm. Interim values are
approximated.
To Next Page
