Westomatic GF Robimat XM - Sliding Door Unit Maintenance; Product Container Maintenance

73
Index
704 67 020 00 _ 111
OPERATING INSTRUCTIONSGF Robimat XL / XM




1 = clean
2 = test/ check
3 = lubricate
4 = replace/ exchange
OK
12 Months or
30,000
1)
24 Months or
60,000
1)
36 Months or
90000
1)
Front drive wheel 2 2 2
Front drive wheel, bearing
Multi-function lubricant
Berulub FR 43
998 90 064 00
3 3 3
Hook-in position of pendulum hook 2 2 2
Legibility of the price/selection labels 2 2 2
Retaining spring
Correctly snapped in;
no damage?
2 2 2




1 = clean
2 = test/ check
3 = lubricate
4 = replace/ exchange
OK
12 Months or
30,000
1)
24 Months or
60,000
1)
36 Months or
90000
1)
Horizontal linear rail, top
Special lubricant
e. g. Microlube GL 261
part no. 998 90 037 01
1+3 1+3 1+3
Horizontal lower guide rail Rinsing water 1 1 1
Damage to horizontal toothed belt 2 2 2
Damage to vertical toothed belt 2 2 2
Deection rollers belt drives (7x) 2+3 2+3 2+3

 Measurement
point: upper centre; vertical rail far
left. 1N with 15mm stretch or 20 Hz
Newton meter 2 2 2
 Measurement point in
centre, basket right at the bottom. 1N
with 15mm stretch or 15 Hz
Newton meter 2 2 2

vertical rail left/right: max. 15 N
Newton meter 2 2 2
Basket upwards: max. 9 N 2 2 2
Basket downwards: max. 6 N 2 2 2
Movable lower ribbon cable loop:
without kink/damage?
2 2 2
Fork light barrier for height
recognition + Y-reference
Brush, air 1+2 1+2 1+2
Micro-switch for X reference 2 2 2
